Product Description

SS Steel gratings consist of a series of bearing bars cross jointed by welding at various intervals with cross bars (twisted square bars, square bars, round bars, flat bars, etc), to form a kind of steel products with square lattices among them.

We can manufacture serrated steel grating to any length and width to meet your specifications.

Material: Carbon Steel

Shape: Flat Shape Manufacturing

Bar Pitch: 15 to 60mm, Customized Cross Bar Pitch: 50 to 100mm, Customized Bearing Bar Dimension: 20*3 to 65*5mm, Various Dimension Panel Size: 995mm*6000mm 1005mm*5800mm

Application: Steel Structure Walkway, Foot Pedal, Drain Cover

Common specification
1)Bearing bar pitches may be 15 to 30, 40, 60, 80 and 90mm; Of which 30and 40mm are recommended
2)Cross bar pitch may be 30, 38, 50, 76 and 100mm; Of which 50 and 100mm are recommended

Finished

1. Hot-DIP galvanizing. It is the process of coating iron or steel with a thin zinc layer by passing the steel through a molten bath of zinc at a temperature of around 860 F (460 C). When exposed to the atmosphere, pure zinc reacts with oxygen to form zinc oxide, which further reacts with carbonate, adult grey, fairly strong material that stops further corrosion in many circumstances, protecting the steel below from the elements. Galvanized steel is widely used in applications where rust resistance is needed.
2. Painting
3. Untreated.
